07 · Harness · 线束

Seat harness 座椅线束

Comp ID 4004105X9D01 · BOM Group 4004105

Seat harness close-up · 座椅线束近景 — Close-up · 近景

Parts / components · 零部件

Terminal label · 端子代号

Terminal label · 端子代号I_S_BI_S_B 座椅对接地板（端子图代号，非 Comp ID）I_S_B Seat↔floor mate (terminal label, not Comp ID)

Materials · 材料

未注明时 FLRY-B 低压导线FLRY-B LV wire (default when unspecified)General LV harness DWG tech requirement per ISO 6722 / Q/WR P1-4 — not exclusive to this family (WH11整车低压线束图纸).

Function · 功能

Seat harness (WH11/WH12 LV & S part tables). Floor-side terminal diagram cites Seat power KL15 (P107) — that pin belongs to the floor harness diagram, not a complete seat-harness function map. Seat-harness own connectors/motors/heaters: unknown. Revisions cite B110/B111; schematic labels include seat B+/GND.

座椅线束（WH11/WH12 低压与 S 图零件表）。地板端子图含 Seat power KL15(P107)——属地板侧供电描述，非座椅线束完整功能。座椅自身连接器/电机/加热清单 unknown。修订含 B110/B111；原理图标签含座椅电源/地。
